Contactor – TeSys Deca LC1D12P7

3P (3NO), AC-3/AC-3e, ≤440V, 12A, 230V AC Coil, Screw Clamp Terminals

The Schneider Electric TeSys D Contactor LC1D12P7 is a reliable 3-pole (3NO) contactor designed for motor and resistive load control up to 12A/440V AC-3/AC-3e. It comes with a 230V AC 50/60Hz coil and 1NO+1NC auxiliary contacts (mirror-certified). Its compact 45 mm design allows for DIN-rail or screw mounting, making it versatile for industrial applications.

✅ Key Features

• Rated Current (Ie): 12A at ≤440V AC (AC-3/AC-3e)

• Motor Power:

  • 5.5 kW at 400V (AC-3/AC-3e)

  • 7.5 kW at 690V (AC-3/AC-3e)

• Auxiliary Contacts: 1 NO + 1 NC (mechanically linked, mirror contact)

• Control Voltage (Uc): 230V AC 50/60Hz

• Durability:

  • Mechanical: 15 million cycles

  • Electrical: 2 million cycles (AC-3 @ ≤440V)

• Protection: IP20 front face, RoHS/REACH compliant

• Certifications: IEC, UL, CSA, CCC, EAC, UKCA, Marine

• Operating Temp.: -40…60°C (up to 70°C with derating)

• Mounting: Rail or plate

• Dimensions (HxWxD): 77 x 45 x 86 mm

• Weight: 0.325 kg

Specifications (Summary)

• Utilisation Categories: AC-1, AC-3, AC-3e, AC-4

• Insulation Voltage: 690V (IEC)

• Impulse Withstand Voltage: 6 kV

• Short-Time Withstand Current: Up to 210 A (1s)

• Operating Rate: Up to 3600 cycles/hour

• Warranty: 18 months
