This Easy9 EU product is a modular flush-mounted enclosure. It is composed of 2 rows of 12 18mm modules. It can accommodate all types of modular devices. It is supplied with 1 earth terminal box and 1 neutral terminal box with their support, and each terminal box has 16 outputs (8×16 mm² + 8×10 mm²). It is equipped with a reversible transparent smoked door with a 180° operating angle. The housing color is white (RAL 9003). This enclosure is dedicated to indoor installation. The IP protection degree is IP40 closed door and IP30 open door. Cables can enter through the 4 sides of the enclosure with pre-cuts for the entry tubes. It is intended for new or renovated installations in the residential sector. The rated current In is up to 63A. The rated insulation voltage Ui is 500 V. The rated operational voltage UE is 400 V. The internal components of the enclosure are a rear box, a removable DIN rail chassis and a front cover with notch. The dimensions are (W) 300mm x (H) 345mm x (D) 99mm. The width in 9mm holes is 48. The product weight is 1.24 kg. The enclosure is made of self-extinguishing plastic. Its resistance to flames and abnormal heat is 650°C, with a duration of 30 minutes according to IEC 60695-2-10. The electrical insulation class is class II (double insulated). The pollution degree is 2. According to IEC 62262, the IK protection degree is IK07. The operating temperature is from -25°C to +60°C. The storage temperature is from -25°C to +70°C. This enclosure complies with IEC 60670-1-24 standard.
Specifications
| Range | Easy9 |
|---|---|
| product name | Easy9 EU |
| Product or component type | enclosure |
| Cabinet type | Modular housing |
| Number of modules per row | 12 |
| cabinet installation | embed |
|---|---|
| Number of 9mm steps per row | 48 |
| total number of 18 mm modules | 24 |
| Rail type | FROM |
| Installation type | inside |
| terminal block function | Earth / neutral |
| number of terminal blocks | 1 earth (screw) with 16 terminals 1 neutral (screw) with 16 terminals |
| Terminal block connections | 8 x 16 mm² + 8 x 10 mm² for earthing 8 x 16 mm² + 8 x 10 mm² for neutral |
| cable entry | Preformed holes |
| Door type | Transparent |
| door opening part | Reversible (180°) |
| [In] rated current | 63 A |
| [Ue] rated operating voltage | 400V |
| [Ui] rated insulation voltage | 500V |
| case material | Self-extinguishing plastic case |
| height | 345mm |
| depth | 99 mm |
| width | 300mm |
| product weight | 1.24 kg |
| Color | Enclosure: white (RAL 9003) Door: smoke |
| standard | IEC 60670-1 IEC 60670-24 |
|---|---|
| IP protection level | IP40 according to SR EN 60529 (door closed) IP30 according to SR EN 60529 (door open) |
| IK protection level | IK07 conforming to IEC 62262 |
| Pollution level | 2 |
| fire resistance | 650 °C 30 min ) conforming to IEC 60695-2-10 |
| electrical insulation class | Class II |
| ambient operating temperature | -25…60 °C |
| ambient temperature for storage | -25…70 °C |
| Unit of measure for the first form of packaging | PCE |
|---|---|
| Number of products in the package | 1 |
| Height of the first packaging form | 10,000 cm |
| Width of the first packaging form | 35,000 cm |
| Length of the first packaging form | 30,000 cm |
| Package Weight(Lbs) | 1,330 kg |
| Unit of measure for the second form of packaging | cart |
| Number of units in the second packaging form | 5 |
| Height of the second packaging form | 53,000 cm |
| Width of the second packaging form | 41,000 cm |
| Length of second packaging form | 31,000 cm |
| Weight of the second packaging form | 7.515 kg |
| Unit of measure for the third form of packaging | P12 |
| Number of units in the third packaging form | 60 |
| Height of the third packaging form | 120,000 cm |
| Width of the third packaging form | 80,000 cm |
| Length of third packaging form | 120,000 cm |
| Weight of the third packaging form | 102,180 kg |
| Guarantee | 18 months |
|---|
